Compare Garmin GFC 500 autopilot systems and upgrade configurations for eligible Mooney M20 series aircraft. This collection brings together available pitch-and-roll systems, automatic pitch trim configurations, yaw damper options and aircraft-specific packages so you can review the available choices for your Mooney in one place.

Garmin autopilot compatibility varies throughout the Mooney M20 family. The correct package depends on your exact aircraft model, serial number, normally aspirated or turbocharged configuration, existing avionics, trim system, aircraft modifications, approved installation data and the capabilities you want included. Neal Avionics can help verify aircraft eligibility and system requirements before you order.

Built for Eligible Mooney M20 Models

Shop aircraft-specific Garmin autopilot packages for select early, mid-generation and later Mooney M20 aircraft.

Compare Complete Configurations

Review pitch-and-roll systems, automatic pitch trim, yaw damper options and available multi-servo packages.

Dealer-Backed Guidance

Get help confirming your aircraft information, installed avionics and desired autopilot capabilities before purchase.

Modern Autopilot Options for the Mooney M20 Series

A modern digital autopilot can make a Mooney M20 more capable and comfortable during cross-country travel, instrument operations and high-workload phases of flight. The Garmin GFC 500 provides an integrated flight-control solution with aircraft-specific configurations available for eligible Mooney M20 airframes.

Depending on the selected package and compatible avionics installed in the panel, available capabilities may include pitch and roll control, heading and navigation tracking, altitude hold, vertical speed and indicated airspeed modes, altitude preselect, vertical navigation, coupled approach guidance, Electronic Stability and Protection and a dedicated Level Mode.

Eligible installations may also support automatic pitch trim, manual electric trim or yaw damping when the required servos and approved equipment are included. These functions can reduce pilot workload while helping maintain a properly trimmed and coordinated aircraft during changing flight conditions.

Every Mooney M20 and instrument panel is different. The appropriate Garmin autopilot package depends on the exact aircraft model, approved system architecture, existing flight instruments, installed navigator, electrical system, trim system, interfaces and the functions you want included in the completed installation.

Choosing the Right Mooney M20 Autopilot Configuration

2-Servo Pitch and Roll Systems

A 2-servo configuration provides powered pitch and roll control. This is the foundation of the Garmin GFC 500 system and may be the right choice for an owner who wants core lateral and vertical flight-control capabilities without adding optional trim or yaw functions.

3-Servo Systems with Automatic Pitch Trim

An automatic pitch trim configuration adds a dedicated trim servo to the pitch-and-roll autopilot. Automatic pitch trim can reduce the need for repeated manual trim adjustments while the autopilot is controlling the aircraft and can help maintain a properly trimmed condition as airspeed, power and vertical modes change.

3-Servo Systems with Yaw Damper

A yaw-equipped configuration adds a dedicated yaw servo when available for the exact aircraft and approved package. Yaw damping can help reduce unwanted yawing motion while improving directional stability, coordination and passenger comfort.

Multi-Servo Systems with Pitch Trim and Yaw Damper

Some eligible Mooney installations may support both automatic pitch trim and yaw damping. These systems require separate servos for pitch, roll, trim and yaw functions. The aircraft approval and individual product package must be reviewed to confirm which functions and components are included.

Early Mooney M20C Through M20G Aircraft

Select M20C, M20D, M20E, M20F and M20G aircraft are eligible for Garmin GFC 500 installations. Model year, serial number, trim-system configuration, aircraft modifications and existing avionics can affect the approved package and installation requirements.

Mooney M20J and M20K Aircraft

The M20J and M20K families include aircraft with different performance, engine and avionics configurations. Packages should be selected using the complete aircraft model and serial number rather than relying only on familiar marketing names such as Mooney 201, 231 or 252.

Mooney M20M, M20R and M20S Aircraft

Later high-performance Mooney aircraft such as eligible M20M, M20R and M20S models may use different installation hardware and approved servo configurations than earlier M20 aircraft. Verify the exact aircraft application before selecting a package intended for a Bravo, Ovation, Eagle or another M20 variant.

Required and Optional Panel Equipment

The GFC 500 operates as part of an integrated avionics system. Compatible electronic flight instruments, displays, navigators, adapters and interfaces may be required to support the selected functions. Review the individual product listing and confirm the complete system requirements before choosing a package.

Mooney M20 Compatibility and Installation Planning

A product title that includes “Mooney M20” does not automatically confirm that the package is approved for every aircraft in the M20 family. Compatibility can depend on the complete model designation, serial number, model year, engine configuration, trim system, installed avionics, aircraft modifications and current approved installation data.

Garmin has published GFC 500 approvals for select M20C, M20D, M20E, M20F, M20G, M20J, M20K, M20M, M20R and M20S aircraft. These models should not be treated as interchangeable because the required hardware, servo configuration and installation provisions can differ throughout the series.

Before requesting a recommendation or installation quote, gather the following aircraft information:

  • Complete aircraft model designation
  • Aircraft serial number and model year
  • Aircraft N-number
  • Normally aspirated or turbocharged configuration
  • Current primary flight instruments
  • Installed GPS or navigation equipment
  • Existing autopilot and trim equipment
  • Manual or electric trim configuration
  • Aircraft modifications or applicable STCs
  • Desired servo configuration and capabilities

Professional Installation Is Required

Certified autopilot equipment requires professional installation. Product pricing does not include installation labor, wiring, circuit protection, installation materials, brackets, control-system work, panel modifications or additional interface equipment unless the individual product listing specifically states otherwise.

Frequently Asked Questions

Mooney M20 Autopilot FAQ

Which Mooney M20 models can use a Garmin GFC 500 autopilot?

Garmin has published GFC 500 approvals for select M20C, M20D, M20E, M20F, M20G, M20J, M20K, M20M, M20R and M20S aircraft. Approval remains model-, serial-number- and installation-specific, so your aircraft information and installed equipment must be checked against current approved data before ordering.

Can an early Mooney M20C, M20D or M20E use the Garmin GFC 500?

Select early and later M20C, M20D and M20E aircraft are eligible for GFC 500 installations. The exact model year, serial number, aircraft modifications, trim system and installed avionics must be verified before selecting a package.

Is the same Garmin autopilot package used for every Mooney M20?

No. The Mooney M20 series includes many aircraft generations with different airframes, engines, trim systems and installation provisions. Select the package using the exact aircraft model and serial number rather than relying only on the general M20 name.

What is the difference between a 2-servo and 3-servo Mooney autopilot?

A 2-servo system provides pitch and roll control. A 3-servo configuration adds another approved function, which may be automatic pitch trim or yaw damping depending on the aircraft and selected package.

Does every Mooney GFC 500 package include automatic pitch trim?

No. Some packages provide the primary pitch-and-roll autopilot without a trim servo, while other configurations include automatic pitch trim. Review the product title, included equipment and approved aircraft application before ordering.

Is a yaw damper available for Mooney M20 aircraft?

Yaw-damper capability may be available for certain eligible Mooney M20 models and approved configurations. It should not be assumed that every M20 aircraft or GFC 500 package supports a yaw servo. The exact aircraft approval and included equipment must be reviewed.

Can a Mooney GFC 500 include both pitch trim and yaw damper?

Some approved aircraft configurations may support both functions when the necessary servos, wiring and equipment are installed. The aircraft model and product package must be reviewed because not every Mooney installation supports the same multi-servo configuration.

What flight instruments are required for a Garmin GFC 500?

Required instruments and interfaces depend on the approved system architecture. Compatible Garmin electronic flight instruments or displays may include the GI 275, G5, G500 TXi or G3X Touch when installed in an approved configuration. Additional navigation and interface equipment may be required for specific functions.

Can a Garmin GFC 500 fly an instrument approach?

When paired with compatible and properly installed navigation equipment, supported GFC 500 configurations can provide coupled navigation and instrument approach capabilities. Available modes depend on the navigator, flight display, installed interfaces and approved aircraft configuration.

Can equipment from the existing Mooney autopilot be reused?

Reuse options depend on the existing system and approved installation design. Do not assume that existing servos, brackets, wiring, trim components or control equipment can be retained without an inspection and installation review.

Does the displayed Mooney M20 autopilot price include installation?

No, unless the individual product listing specifically states that installation is included. Installation labor, wiring, circuit protection, brackets, control-system work, panel modifications, additional avionics and interface equipment can affect the final project price.

How do I know which Mooney M20 autopilot package to order?

Provide Neal Avionics with your complete aircraft model designation, serial number, model year, N-number, current panel equipment, existing autopilot information and desired capabilities. Our team can help identify the appropriate configuration and determine what additional equipment or installation planning may be required.

Aircraft-Specific Assistance

Not Sure Which Autopilot Is Right for Your Mooney M20?

Garmin autopilot packages can look similar while containing important model-, trim- and installation-specific differences. Contact Neal Avionics before ordering and let our team help verify the correct system for your aircraft, panel and desired capabilities.

Request an Installation Quote
