Beechcraft Bonanza Autopilot Systems

Beechcraft Bonanza Autopilot Systems

Shop Beechcraft Bonanza autopilot systems, including Garmin GFC 500/600 pitch-and-roll, automatic pitch trim and yaw damper configurations.

Skip to results list
Availability
Price
to
The highest price is $18,655.00
Clear
24 items

Filter

Availability
Price
to
The highest price is $18,655.00

Compare Garmin GFC 500 autopilot systems and upgrade configurations for eligible Beechcraft Bonanza series aircraft. This collection brings together available pitch-and-roll systems, automatic pitch trim configurations, yaw damper options and fully equipped multi-servo packages so you can review the available choices for your aircraft in one place.

Garmin autopilot compatibility varies throughout the Bonanza family. The correct package depends on your exact aircraft model, serial number, tail configuration, existing avionics, modifications, approved installation data and the capabilities you want included. Neal Avionics can help verify aircraft eligibility and system requirements before you order.

Built for Eligible Bonanza Models

Shop aircraft-specific Garmin autopilot packages for select conventional-tail and V-tail Beechcraft Bonanza aircraft.

Compare Complete Configurations

Review core pitch-and-roll systems, automatic pitch trim, yaw damper and available multi-servo configurations.

Dealer-Backed Guidance

Get help confirming your aircraft information, installed avionics and desired autopilot capabilities before purchase.

Modern Autopilot Options for the Beechcraft Bonanza

A modern digital autopilot can make a Beechcraft Bonanza more capable and comfortable during cross-country travel, instrument operations and high-workload phases of flight. The Garmin GFC 500 provides an integrated flight-control solution with aircraft-specific configurations available for eligible Bonanza and Debonair airframes.

Depending on the selected package and the compatible avionics installed in the panel, available capabilities may include pitch and roll control, heading and navigation tracking, altitude hold, vertical speed modes, airspeed modes, altitude preselect, vertical navigation, coupled approach guidance, Electronic Stability and Protection and a dedicated Level Mode.

Eligible installations may also support automatic pitch trim, manual electric trim or yaw damping when the required servos and approved equipment are included. These capabilities can reduce pilot workload and help provide smoother, more coordinated flight.

Every Bonanza and instrument panel is different. The appropriate Garmin autopilot package depends on the exact aircraft model, approved system architecture, existing flight instruments, installed navigator, electrical system, interfaces and the functions you want included in the completed installation.

Choosing the Right Bonanza Autopilot Configuration

2-Servo Pitch and Roll Systems

A 2-servo configuration provides powered pitch and roll control. This is the foundation of the Garmin GFC 500 system and may be the right choice for an owner who wants core lateral and vertical flight-control capabilities without adding optional trim or yaw functions.

3-Servo Systems with Automatic Pitch Trim

An automatic pitch trim configuration adds a dedicated trim servo to the pitch-and-roll autopilot. Automatic pitch trim can reduce the need for repeated manual trim adjustments while the autopilot is controlling the aircraft and can help keep the aircraft properly trimmed as flight conditions change.

3-Servo Systems with Yaw Damper

A yaw-equipped configuration adds a dedicated yaw servo when available for the selected aircraft and approved package. Yaw damping can help reduce unwanted yawing motion and improve directional stability, coordination and passenger comfort.

Multi-Servo Systems with Pitch Trim and Yaw Damper

Some eligible Bonanza installations may support both automatic pitch trim and yaw damping. These configurations include separate servos for pitch, roll, trim and yaw functions. The aircraft approval and individual product package must be reviewed to confirm which functions and components are included.

V-Tail and Conventional-Tail Aircraft

The Beechcraft Bonanza family includes both V-tail and conventional-tail aircraft across several model generations. Autopilot hardware, installation requirements and approved configurations can differ between aircraft families, even when the products appear similar. Always select a system prepared for the exact model and serial-number range.

Required and Optional Panel Equipment

The GFC 500 operates as part of an integrated avionics system. Compatible electronic flight instruments, displays, navigators, adapters and interfaces may be required to support the selected functions. Review the individual product listing and confirm the complete system requirements before choosing a package.

Beechcraft Bonanza Compatibility and Installation Planning

A product title that includes “Beechcraft Bonanza” does not automatically confirm that the package is approved for every Bonanza aircraft. Compatibility can depend on the exact model, serial number, tail configuration, engine and electrical configuration, installed avionics, modifications and current approved installation data.

Depending on the aircraft, eligible models may fall within the Bonanza 33-series, 35-series or 36-series families. Some Debonair models may also share approved Garmin autopilot applications. Exact aircraft eligibility must be verified before equipment is ordered.

Before requesting a recommendation or installation quote, gather the following aircraft information:

  • Exact aircraft model and serial number
  • Aircraft N-number
  • V-tail or conventional-tail configuration
  • Normally aspirated or turbocharged configuration
  • Current primary flight instruments
  • Installed GPS or navigation equipment
  • Existing autopilot and trim equipment
  • Aircraft modifications or applicable STCs
  • Desired servo configuration
  • Desired approach and navigation capabilities

Professional Installation Is Required

Certified autopilot equipment requires professional installation. Product pricing does not include installation labor, wiring, circuit protection, installation materials, brackets, control-system work, panel modifications or additional interface equipment unless the individual product listing specifically states otherwise.

Frequently Asked Questions

Beechcraft Bonanza Autopilot FAQ

Which Beechcraft Bonanza models can use a Garmin GFC 500 autopilot?

The Garmin GFC 500 is approved for select aircraft across the Bonanza 33-series, 35-series and 36-series families, as well as certain Debonair models. Approval is model-, serial-number- and installation-specific, so your aircraft information and installed equipment must be checked against current approved data before ordering.

Can the Garmin GFC 500 be installed in a V-tail Bonanza?

The GFC 500 is approved for select V-tail Bonanza models. The exact model, serial number, aircraft modifications and existing avionics must be verified because approval and installation requirements are not identical across every 35-series aircraft.

Can the Garmin GFC 500 be installed in a straight-tail Bonanza or Debonair?

Select conventional-tail Bonanza and Debonair aircraft are eligible for GFC 500 installations. Compatibility depends on the specific aircraft model, serial-number range, modifications and approved equipment configuration.

What is the difference between a 2-servo, 3-servo and multi-servo Bonanza autopilot?

A 2-servo system provides pitch and roll control. A 3-servo package may add either automatic pitch trim or yaw damping, depending on the selected configuration. Some eligible packages may include separate servos for both trim and yaw functions in addition to the primary pitch and roll servos.

What is the difference between automatic pitch trim and yaw damper?

Automatic pitch trim adjusts the aircraft’s pitch trim while the autopilot controls pitch. A yaw damper uses the applicable yaw-control system to reduce unwanted yawing motion and improve coordination. They perform separate functions and require different servos and approved installation provisions.

Can a Bonanza GFC 500 include both pitch trim and yaw damper?

Some eligible aircraft configurations may support both functions when the required servos, wiring and approved equipment are installed. The aircraft model and individual package must be reviewed because not every Bonanza installation supports the same configuration.

What flight instruments are required for a Garmin GFC 500?

The required instruments and interfaces depend on the approved system architecture. Compatible Garmin electronic flight instruments or displays may include equipment such as the GI 275, G5, G500 TXi or G3X Touch when installed in an approved configuration. Additional navigation and interface equipment may be required for specific functions.

Can a Garmin GFC 500 fly an instrument approach?

When paired with compatible and properly installed navigation equipment, supported GFC 500 configurations can provide coupled navigation, instrument approach and missed-approach capabilities. Available modes depend on the navigator, flight display, installed interfaces and approved aircraft configuration.

Can an existing Bonanza autopilot be upgraded one component at a time?

Upgrade options depend on the existing system, installed servos, wiring, flight instruments and current aircraft approval. Do not assume that components from an older autopilot or another GFC 500 package can be reused without an installation review.

Does the displayed Bonanza autopilot price include installation?

No, unless the individual product listing specifically states that installation is included. Installation labor, wiring, circuit protection, brackets, control-system work, panel modifications, additional avionics and interface equipment can affect the final project price.

How do I know which Beechcraft Bonanza autopilot package to order?

Provide Neal Avionics with your exact aircraft model, serial number, N-number, current panel equipment, existing autopilot information and desired capabilities. Our team can help identify the appropriate configuration and determine what additional equipment or installation planning may be required.

Aircraft-Specific Assistance

Not Sure Which Autopilot Is Right for Your Beechcraft Bonanza?

Garmin autopilot configurations can look similar while containing important aircraft-, tail- and installation-specific differences. Contact Neal Avionics before ordering and let our team help verify the correct system for your aircraft, panel and desired capabilities.

Request an Installation Quote
